duotight - 9.5mm (3/8) x 6.35mm(1/4) Female Reducing Tee
KL43137
$2.85
If you need to split your 6.35mm OD hose into two 9.5mm OD hoses, or split a 9.5mm OD hose into a 6.35mm OD hose and another 9.5mm hose, this fitting's what you need.
Applications & Compatibility
- 6.35mm EVABarrier: Split it into two 9.5mm hoses!
- 9.5mm EVABarrier: Split it into one 6.35mm hose and one 9.5mm hose!
6.35mm Tubing Compatibility
This 6.35mm duotight fitting is optimised for use with EVABarrier Dual Barrier Line. It is compatible with:
- KL25331 : 3mm ID x 6.35mm OD | 12m
- KL42758 : 3mm ID x 6.35mm OD | 12m (Red)
- KL42789: 3mm ID x 6.35mm OD | 12m (Black Lightshield)
- KL42758 : 3mm ID x 6.35mm OD | 12m (PE Water Line)
9.5mm Tubing Compatibility
This 9.5mm duotight fitting is optimised for use with EVABarrier Dual Barrier Line. It is compatible with:
- KL06248: 6.3mm ID x 9.5mm OD | 12m
- KL42772: 6.3mm ID x 9.5mm OD | 12m (Black Lightshield)
The duotight Generation 2 Difference
Why settle for standard push-in fittings? duotight Generation 2 represents a massive leap in engineering over traditional acetal fittings.
Dual-Material Double O-Ring Design
The secret to our superior seal is a two-stage system using two different high-quality materials:
- EPDM O-Ring: Provides exceptional chemical and gas resistance.
- Silicone O-Ring: Maintains its shape and elasticity in sub-zero temperatures.
High-Performance Materials (POK)
Instead of standard Acetal, Generation 2 fittings are made from Polyketone (POK).
- Higher Chemical Resistance: Withstands harsh brewery cleaners.
- UV Protection: Won't become brittle over time.
- Extreme Durability: Rated for over 300psi @ 25°C.
User-Friendly Features
- Color-Coded Collets: Green denotes 6.35mm (1/4").
- Depth Indicators: Includes >| |< indicators so you know the hose is fully seated.
- No Clamps Necessary: Simply push to seal; push the collet to release.
We recommend using a Tube Cutter to ensure a perfectly straight, burr-free cut. An angled cut is the #1 cause of leaks in push-fit systems.
